Introduction

Plumbing is one of those things we often take for granted until it stops working. Yet, behind every faucet, toilet, and drain is a complex system that quietly protects our health, supports our daily routines, and keeps our buildings safe and functional. Whether in homes, offices, factories, or hospitals, plumbing systems are essential to modern life.

To keep these systems safe, reliable, and efficient, Canada relies on a national framework called the National Plumbing Code of Canada (NPC). This code lays out the rules for designing, installing, and maintaining plumbing systems across the country, making sure everything works the way it should no leaks, no surprises.

In Ontario, these national guidelines are adapted into the Ontario Building Code (OBC). The OBC is more than just a rulebook it’s the law when it comes to building construction, including plumbing. The latest edition, coming into effect on January 1, 2025, aligns closely with updates from the NPC 2020. These changes reflect the latest thinking in construction practices, environmental sustainability, and energy efficiency.

But understanding the plumbing code isn’t just about following rules. It’s about building smarter, safer, and more sustainable systems. A solid grasp of the code helps ensure that plumbing:

• Protects the health and safety of people,
• Uses water and energy wisely,
• Supports long-lasting and accessible infrastructure,
• Keeps pace with new technologies and materials.

For professionals like plumbers, contractors, engineers, architects, and inspectors, knowing the plumbing code inside and out isn’t optional it’s a crucial part of getting the job done right from start to finish.

This article will walk you through the structure and core principles of the Canadian Plumbing Code, with a special focus on how Ontario puts it into practice. Along the way, we’ll explore key sections, technical details, and the latest updates in the 2024 OBC. With diagrams, references, and real-life examples, this guide is here to help you stay informed, compliant, and confident in your work.



Part 1: Understanding the Structure of the Canadian Plumbing Code

If you’ve ever opened the Canadian Plumbing Code (CPC), you know it’s not light reading. But understanding how it’s organized is the first step to using it effectively on real-world jobs whether you're designing a plumbing system, installing one, or inspecting a finished project.

The code is built on a clear structure that separates the “why,” the “how,” and the “who’s responsible.” This smart layout doesn’t just help with rule-following it also opens the door for innovation and flexibility through performance-based solutions.





🔧 The Three-Part Framework

The Canadian Plumbing Code follows what’s called a three-division model. This setup is used across all the national construction codes in Canada and is published by the Canadian Commission on Building and Fire Codes (CCBFC), under the National Research Council (NRC).

Let’s break down the three divisions:



🔧 Division A – The Purpose Behind the Rules

Division A is where you find the big picture. It explains why the rules exist and how you can prove your system meets code even if you're using non-traditional solutions.

Here’s what’s in it:

• Compliance Paths: You can meet the code in two ways by following the standard step-by-step rules (in Division B), or by using alternative solutions that still meet performance goals.
• Objectives (O-1 to O-3):
  • O-1: Safety – Keeping people safe (e.g., avoiding water contamination).
  • O-2: Health – Maintaining sanitary and hygienic conditions.
  • O-3: Environmental Protection – Reducing waste and conserving water.
• Functional Statements: These link the rules in Division B to their purposes. For instance, the rule about trap seal depth exists to stop sewer gases from getting inside (linked to functional statement F-02).

Division A is especially important if you're using new materials or techniques that aren’t spelled out in the code but still achieve the same level of safety and performance.



🛠️ Division B – The Practical Rules You Use on the Job

This is the go-to section for most tradespeople. It gives the prescriptive requirements in other words, the detailed “how-to” for plumbing systems that are already approved as compliant.

Division B covers:

• Water supply and distribution
• Drainage, waste, and vent systems (DWV)
• Fixtures and appliances
• Storm drainage
• Non-potable and reclaimed water systems
• Materials, fittings, and sizing charts

In Ontario, this section mostly follows the national code, but there are provincial amendments. For example, Ontario might have stricter rules on backflow prevention or different sizing standards for pipes. These local changes are noted in the Ontario Code Compendium often with an asterisk or a comment box.



🛠️ Division C – The Rules for Running the Show

Division C lays out the administrative side of the code. This part is especially useful for city officials, inspectors, and anyone dealing with permits or enforcement.

It includes:

• Permit and application processes
• Licensing requirements (like becoming a certified master plumber)
• Site inspections and approvals
• How code violations are handled
• What records municipalities need to keep

In Ontario, Division C is shaped by the Building Code Act, 1992, which sets the legal framework for how the code is applied, enforced, and challenged.





1.2 How the Plumbing Code Fits into the Bigger Picture

The Canadian Plumbing Code (CPC) doesn’t stand alone. It’s part of a broader network of national construction codes that work together to keep buildings safe, efficient, and sustainable.

Some of its closest “relatives” include:

• National Building Code (NBC) – Sets the structural and architectural rules.
• National Fire Code (NFC) – Focuses on fire safety, prevention, and suppression.
• National Energy Code for Buildings (NECB) – Promotes energy efficiency in building systems.

In addition to these model codes, the CPC relies on third-party standards from trusted organizations like:

• CSA Group (Canadian Standards Association)
• NSF International
• ASTM International
• ASME (American Society of Mechanical Engineers)

These standards provide the technical benchmarks for plumbing components things like how pipes should be tested, what fittings are certified, and the performance requirements for valves and fixtures.

In Ontario, professionals follow the Ontario Building Code (OBC), which incorporates the CPC but adds provincial modifications. For example, the 2024 Ontario Building Code which takes effect on January 1, 2025 includes the latest updates from the 2020 edition of the NPC, customized to meet Ontario's specific needs.





1.3 Key Features to Know About the Code’s Structure

To navigate the code like a pro, it helps to understand a few formatting tools built into it:

• Numbering System: Clauses in Division B use a decimal system (e.g., 2.2.10.6) that makes it easier to locate related topics.
• Appendices: These offer helpful explanations, examples, and commentary but they aren’t legally binding unless directly referenced.
• Tables: Provide critical measurements and calculations like:
• Minimum pipe sizes
• Fixture unit values
• Drain slopes
• Trap seal depths
• Amendment Notes: Ontario-specific changes to the national code are clearly marked often with symbols like an asterisk (*) or side notes in the OBC.
•



1.4 Why the Structured Format Matters

The Canadian Plumbing Code is carefully organized for good reason it’s built to be clear, flexible, and consistent:

• ✅ Clarity – The three-division layout helps users find the info they need faster.
• 🔄 Flexibility – Encourages new approaches through alternative solutions that meet performance targets.
• 👷 Accountability – Defines who’s responsible for meeting the code and enforcing it (e.g., building officials, licensed contractors).
• 🇨🇦 Consistency – Promotes nationwide standards while giving provinces room to adapt for local needs.
•



📊 Visual Aid: How the Code Is Structured

You can think of the CPC as a 3-layer system:

+--------------------------+

|  Canadian Plumbing Code  |

+--------------------------+

         |

         +--> Division A - Why the rules exist (objectives & compliance)

         |

         +--> Division B - How to meet the rules (technical solutions)

         |

         +--> Division C - Who enforces the rules (admin & permitting)



📚 Reference Sources

1. National Plumbing Code of Canada 2020 – NRC Canada
2. Ontario Building Code 2024 – Ontario Ministry of Municipal Affairs and Housing
3. Building Code Act, 1992 – Government of Ontario
4. CSA Standards Database – CSA Group





🔹 2.1 – Water Supply and Distribution

Clean, safe water is one of the cornerstones of good plumbing. Whether it’s a shower, kitchen tap, or dental chair, every fixture in a building depends on a well-designed potable water system to deliver the right amount of water at the right pressure.

✅ What the Code Requires:

• Pipe Sizing: Pipes must be sized based on flow demand and the number of plumbing fixtures. In the 2020 NPC, fixture unit values and sizing tables were updated for greater accuracy and reliability.
• Approved Materials: Only code-compliant materials are allowed for water supply piping. These include:
  • PEX (CSA B137.1)
  • CPVC (CSA B137.3)
  • Copper (ASTM B88)
• Water Pressure:
  • Minimum: 200 kPa (30 psi) is typically recommended.
  • Maximum: 550 kPa (80 psi) at fixtures unless a pressure-reducing valve (PRV) is used.
• Backflow Protection: Devices must be installed to prevent contaminated water from flowing backward into the clean water supply. They must comply with CSA B64.10.

🔧 Real-World Example:

• All new homes and commercial buildings need backflow prevention on exterior hose bibs and irrigation lines.
• Facilities like hospitals or dental clinics, where contamination risks are higher, must use Reduced Pressure (RP) backflow preventers for certain fixtures.

📚 Code References:

• NPC 2020 – Section 2.6
• OBC 2024 – Part 7, Clause 7.6



🔹 2.2 – Drainage, Waste, and Vent (DWV) Systems

If the water supply is the lifeblood of plumbing, then the DWV system is its backbone. These systems safely remove wastewater and sewage from buildings while keeping sewer gases out of living areas.

✅ What the Code Requires:

• Trap Seals:
  • Minimum depth: 38 mm (1.5")
  • Purpose: To block unpleasant and harmful gases from coming back into occupied spaces.
• Vent Pipe Sizing: Based on how many fixture units are connected. The code allows wet venting (shared vent pipes) under certain conditions.
• Pipe Slopes:
  • Pipes ≤ 3" diameter: Minimum slope of 1:50 (2%)
  • Pipes ≥ 4" diameter: Minimum slope of 1:100 (1%)
• Approved Materials: Common options include:
  • ABS and PVC (CSA B181.1 or B181.2)
  • Cast iron
  • Copper

🔧 Real-World Example:

• Wet venting is popular in bathroom layouts to save space and reduce material costs but the rules around pipe size and layout must be followed carefully.
• Cleanouts (access points for clearing blockages) are required at every major change in direction especially angles greater than 45°.

📚 Code References:

• NPC 2020 – Section 2.4
• OBC 2024 – Part 7, Clause 7.4





🔹 2.3 – Plumbing Fixtures and Appliances

From toilets to dishwashers, plumbing fixtures are where the system meets the user. This section of the code ensures that every sink, shower, and appliance not only functions properly but does so safely and efficiently.

✅ What the Code Requires:

• Approved Fixtures: Every fixture must meet performance and safety standards, such as:
  • CSA B45.1 for toilets and sinks
  • ASME and CSA standards for appliances
• Water Efficiency:
  • Toilets: Must use no more than 4.8 litres per flush (dual-flush models may be rated at 6/3 Lpf).
  • Urinals: High-efficiency models must not exceed 1.9 litres per flush.
  • Showerheads: Flow limited to 7.6 L/min at 550 kPa pressure.
• Temperature Control:
  • Mixing valves (CSA B125.3) are required to blend hot and cold water safely in bathtubs and showers.
  • Max temperature at outlets used by the public or in healthcare settings is 49°C (120°F) to prevent scalding.

🔧 Real-World Example:

• In daycares and senior homes, scald prevention is a must thermostatic mixing valves ensure safe water temperatures at all times.
• Hands-free faucets are required for public handwashing sinks in many cities, reducing both contamination and water waste.

📚 Code References:

• NPC 2020 – Section 2.2
• OBC 2024 – Part 7, Clauses 7.2 & 7.6



🔹 2.4 – Non-Potable and Reclaimed Water Systems

Using recycled or non-drinkable water isn’t just a trend it’s a smart and sustainable choice, especially in green building projects. This section of the code sets the standards for safely using greywater, rainwater, and other non-potable water sources.

✅ What the Code Requires:

• Where You Can Use It:
  • Toilet and urinal flushing
  • Landscape irrigation
  • Cooling towers and industrial applications
• Keeping Systems Separate:
  • Non-potable pipes must be clearly labeled (often purple)
  • Must have air gaps or physical separation from potable water lines to prevent cross-contamination
• Water Treatment & Testing:
  • Systems must meet CSA performance standards like CSA B128.3
  • Greywater reuse systems must be tested to ensure they’re safe and reliable

🔧 Real-World Example:

• In LEED-certified or Net-Zero buildings, greywater recycling systems are used to reduce strain on municipal water supplies.
• Backflow prevention is mandatory on every non-potable water system to keep drinking water safe.

📚 Code References:

• NPC 2020 – Sections 2.6.1 & 2.7
• OBC 2024 – Clauses 7.6.1 & 7.7



🔹 2.5 – Storm Drainage and Sump Pump Systems

When heavy rain hits, a well-designed stormwater system can make the difference between a dry basement and a costly flood. This section of the plumbing code deals with storm drainage, sump pumps, and foundation drainage to help buildings manage water runoff safely and effectively.

✅ What the Code Requires:

• Roof Drainage:
  • Systems must be designed to handle local rainfall intensity, measured in mm/hour, using data from Environment Canada.
• Sump Pits & Pumps:
  • Sump pits must have sealed covers to prevent odours and gases.
  • Sump pumps must discharge above grade (onto the lawn or driveway) or directly into a storm drainage system never into the sanitary sewer.
• Weeping Tiles (Foundation Drains):
  • Must be connected to a sump pit or a storm sewer.
  • Connection to sanitary sewers is strictly prohibited this helps avoid overloading treatment plants and prevents basement backups.

🔧 Real-World Example:

• In many flood-prone areas like Toronto, backwater valves and sump pump systems are now required by law for new residential builds.
• Downspouts (roof leaders) must be disconnected from sanitary sewer lines a mandatory step in several Ontario municipalities to prevent sewer overload and urban flooding.

📚 Code References:

• NPC 2020 – Section 2.5
• OBC 2024 – Clause 7.8



📊 Visual Reference: Simplified Plumbing Code Map

Plumbing Code Structure:

 ├─ Water Supply & Distribution (2.6)

 ├─ Drainage, Waste & Vent Systems (2.4)

 ├─ Fixtures & Appliances (2.2)

 ├─ Non-Potable & Reclaimed Water (2.6.1, 2.7)

 └─ Stormwater & Sump Systems (2.5)



📚 Reference Sources for Part 2:

1. National Plumbing Code of Canada 2020 – NRC Canada
2. 2024 Ontario Building Code Compendium – Ontario Government
3. CSA Group – Plumbing Standards
4. Canadian Institute of Plumbing & Heating (CIPH)



🔸 Part 3: What’s New in the 2024 Ontario Building Code (OBC)

Big changes are coming. Starting January 1, 2025, the 2024 edition of the Ontario Building Code officially kicks in and with it, a host of updates to plumbing standards. These changes are designed to:

• Align with the 2020 National Plumbing Code of Canada
• Reflect new technologies and best practices
• Promote water conservation, public health, and climate resilience

This section will walk you through the most important updates and how they’ll affect plumbing design, material use, and compliance going forward.





🔄 3.1 – Harmonizing with the National Plumbing Code 2020

As of 2024, Ontario is aligning more closely with the National Plumbing Code (NPC) 2020 a big move toward consistency across Canada. While the province still keeps a few of its own rules, this harmonization helps plumbing professionals apply best practices that are recognized nationwide.

✳ What’s Aligned:

• Fixture Unit Values & Pipe Sizing: Ontario now uses the same revised formulas and tables from NPC 2020, improving accuracy and design consistency.
• CSA Standards: The latest CSA standards for materials, products, and installation methods are now fully referenced.
• Wet & Circuit Venting: The code now provides clearer guidelines and more flexibility for designing multi-fixture vent systems.
• Low-Rise Residential Plumbing: More options for creative, efficient layouts great news for custom home builders and renovators.

📌 Source: Ontario Ministry of Municipal Affairs and Housing







💧 3.2 – Stronger Water Efficiency Standards

With growing concerns about climate change, urban growth, and infrastructure limits, water conservation is a top priority in the new OBC. The updated rules raise the bar for fixture performance and promote eco-friendly building practices.

🚿 New Performance Limits:

• Toilets: Max 4.8 L per flush; dual flush up to 6/3 Lpf
• Urinals: Max 1.9 L per flush
• Showerheads: Max 7.6 L/min at 550 kPa
• Faucets:
  • Residential: Max 5.7 L/min
  • Public restrooms: Max 1.9 L/min

🧯 Other Key Requirements:

• Only CSA-certified low-flow fixtures are permitted in new builds.
• Older high-flow fixtures are banned from new construction or major renovations.
• Testing must comply with CSA B125, CSA B45, and ASME A112 performance series.

🌱 Why It Matters:

These changes directly reduce water consumption, ease the burden on municipal systems, and help builders achieve LEED, Net-Zero, or ENERGY STAR certifications.

📌 Source: CSA B125 & B45 Standards





🧰 3.3 – Smarter Pipe Sizing & Fixture Unit Calculations

One of the most technical but impactful updates is the revision of pipe sizing methods. The new system is based on modern water use patterns and real-world performance data, ensuring systems are right-sized and efficient.

🔍 What’s Changed:

• Fixture Unit Tables: Fully revised tables now reflect current flow data and fixture diversity.
• Probability-Based Sizing: Helps balance flow demand between cold and hot water lines more precisely.
• Updated Design Tools:
  • New calculation sheets
  • Tables that reduce oversizing, material costs, and stagnant water risks
  • Better performance with low-flow fixtures

📈 Why It’s Better:

• Energy Efficient: Smaller pipes = less heat loss from hot water lines.
• Material Savings: You’ll use less copper, PEX, and fittings.
• Performance Control: Systems are more balanced and less prone to pressure spikes or drops.

📘 Example: Section 7.6.3 in the OBC now includes updated versions of Tables A-2.6.3.1 and 2.6.3.2.





🚫 3.4 – Cross-Connection and Backflow Prevention

Protecting our drinking water is more important than ever. Contaminated water from backflow incidents like hose bibs left in dirty water or cross-connections between potable and non-potable systems can pose serious health risks.

That’s why the new code takes a stronger stance on backflow prevention, especially in residential, commercial, and institutional settings.

✅ Key Code Requirements:

• CSA B64.10 and B64.11 devices are now expanded into residential systems, not just commercial buildings.
• In flood-prone areas, backwater valves are mandatory to protect homes from sewer backups.
• Public buildings and facilities (e.g., schools, hospitals) must:
  • Conduct annual backflow testing
  • Install RPZ (Reduced Pressure Zone) devices at key points in the water system

📍 Ontario-Specific Rule:

Municipalities can now require “premise isolation” backflow devices in high-risk areas like:

• Industrial buildings
• Hospitals
• Water treatment plants

This gives local authorities more control to protect public health in vulnerable zones.





🏗 3.5 – Greywater, Rainwater & Non-Potable Water Systems

With Ontario embracing greener building strategies, the new code promotes the use of alternative water sources like rainwater and greywater especially for non-drinking purposes.

💡 What’s New:

• The code officially adopts CSA B128.3, the national standard for greywater reuse systems.
• Non-potable water systems, such as those for:
  • Toilet flushing
  • Irrigation
  • Cooling towers
    must include:
  • Clearly labeled/color-coded piping
  • Air gaps or approved backflow prevention to separate from the potable supply
• Inspection guidelines for these dual-pipe systems are now clearly outlined

These systems are now approved for use in multi-residential and commercial buildings, provided they follow strict safety protocols.





⚠️ 3.6 – Flood Protection, Sump Systems, and Drainage

Flooding is a growing concern especially in Southern Ontario and the GTA. The new OBC includes several changes aimed at protecting properties from water damage and improving stormwater resilience.

🧱 Key Flood Protection Measures:

• Backwater valves are now mandatory in all new residential builds
• Sump pits must have sealed lids and, in some cases, alarms to notify occupants of pump failure or overflow
• Foundation drainage (e.g., weeping tile) can no longer connect to sanitary sewer lines
• Storm drainage sizing has been updated to match Environment Canada’s new rainfall intensity data

These updates align with flood mitigation strategies recommended by the Ministry of Natural Resources and local municipalities.







📊 Visual Summary: 2024 Plumbing Code Changes



Code Area	New 2024 OBC Requirement	Relevant Code Section
Water Efficiency	Low-flow fixtures required	Part 7, 7.6
Pipe Sizing	New fixture unit values and pipe sizing tables	Part 7, 7.6.3
Backflow Protection	Expanded CSA B64 scope and annual testing	Part 7, 7.6.2
Non-Potable Systems	Must meet CSA B128.3 for greywater reuse	Part 7, 7.7
Flood Protection	Backwater valves, sump alarms required	Part 7, 7.4.9, 7.8
Fixture Certification	CSA/ASME-compliant fixtures mandated	Part 7.2, 7.6



📚 Reference Sources:

1. 2024 Ontario Building Code Compendium (Parts 7 & 9)
2. National Plumbing Code of Canada 2020 – NRC
3. CSA Group – Plumbing Standards
4. Canadian Institute of Plumbing & Heating (CIPH)
